1.Excellent workers
2.Strict Quality Control
3.Top quality products
4.Innovative design team
5.Fastest lead time
6.The most rapid reply
7.Highly efficient management
8. Customized to meet your unique specs
9. Factory visit warmly welcomed
10.Convenient transportation
11. Vibration Resistance
| Item | Aluminium ipe/pipes Aluminium Tube/Tubes/tubing |
| Material | Aluminium |
| Grade | 1000 series: 1050,1060,1070,1080,1100,1435, etc 2000 series: 2011,2014,2017,2024, etc 3000 series: 3002,3003,3104,3204,3030, etc 5000 series: 5005,5025,5040,5056,5083, etc 6000 series: 6101,6003,6061,6063,6020,6201,6262,6082, etc 7000 series: 7003,7005,7050,7075, etc |
| standards | ASTM, ASME,EN, JIS, DIN,GB/T etc |
| Size | Outer Diameter:3-250mm |
| Wall Thickness: 0.3-50mm | |
| Length: 10mm -6000mm | |
| Surface treatment | Mill finish Anodized Electrophoresis Powder coating Wooden grain Sand blast |
| Surface colors | Nature, silver, bronze, champagne, black, gloden, etc As customized |
| Temper | T3-T8 |
| Application | 1. Lighting,solar reflector plate. 2.architectural appearance, interior decoration:ceiling,metope, furniture,cabinets and so on. 3.elevator,nameplate, bags. 4.automotive interior and exterior decoration. 5. Interior decoration: such as photo frame. 6.household appliances, refrigerator, microwave oven, audio equipment. 7. Aerospace and military aspects. 8, machinery parts processing, mold manufacturing . 9. chemical/insulation pipeline coating. |
| Alloy | Si | Mg | Fe | Cu | Mn | Zn | Cr | Ti |
| 1050 | 0.25 | 0.05 | <0.40 | <0.05 | <0.05 | <0.05 | - | <0.03 |
| 3003 | 0.6 | - | 0.7 | 0.05 -0.20 | 1.0-1.5 | 0.10 | - | - |
| 5052 | 0.25 | 2.2-2.8 | 0.4 | 0.1 | 0.1 | 0.10 | 0.15-0.35 | - |
| 5083 | 0.4 | 4.0-4.9 | 0.4 | 0.1 | 0.4-1.0 | 0.25 | 0.05-0.25 | 0.15 |
| 6005 | 0.6-0.9 | 0.4-0.6 | <0.35 | <0.1 | <0.1 | <0.1 | <0.1 | <0.1 |
| 6061 | 0.4-0.8 | 0.8-1.2 | <0.70 | 0.15-0.4 | <0.15 | <0.25 | 0.04-0.35 | <0.05 |
| 6063 | 0.2-0.6 | 0.45-0.9 | <0.35 | <0.1 | <0.1 | <0.1 | <0.1 | <0.1 |
| 6082 | 0.7-1.3 | 0.6-1.2 | <0.50 | <0.1 | 0.4-1.0 | <0.2 | <0.25 | <0.10 |
